Solar Refrigerator – DC Powered

Sirv gallery: 1 imageDelete GalleryEdit Gallery

C4P Inc. can arrange OEM and ODM for a variety of solar refrigerator models ranging from 6.1 to 11.1 cubic feet in capacity. These solar fridges are an exceptional choice for use as an RV refrigerator, in an aquatic vessel, or in off-grid housing; no inverters are needed, our solar refrigerators can run straight from batteries. This means that the energy generated from your solar panels goes directly into powering your refrigerator without needing to convert back to AC and waste energy.

All of our DC refrigerator models are equipped with an automatic voltage detection switch, so your 12 volt refrigerator can flawlessly switch to a 24 volt refrigerator. With an automatic defrost and a 7 setting thermostat, these solar fridges are designed to be off-grid kitchen necessities. Our patented compressor design allows any of our solar fridge models to be powered by one 220 watt solar panel. C4P Inc. is also a manufacturing agent for a line of solar freezers.

Please sign and fill out the Voltray & SunStar Warranty Card

(Right click and save the PDF file)

Features

  • 12v / 24v DC Power
  • Adjustable temperature control
  • Top Refrigerator / Bottom Freezer
  • Automatic interior LED lights
  • Adjustable shelving in refrigerator compartment
  • Drawers included in freezer compartment
  • Manual ice maker
  • No inverters required

Suitable Locations

  • Hunting & Fishing Camps
  • Homes & Cabins
  • Medical
  • Markets & Stores
  • Remote locations requiring an off-grid refrigerator


Solar Refrigerator Models




Model: C4P11.1SRVR



Total Volume
315 Liters / 11.1 cu.ft
Freezer Volume
96.5 Liters / 3.4 cu.ft
Refrigerator Volume
218 Liters / 7.7 cu.ft
Rated Operation Voltage
12V 9.6-17 / 24V 21-31.5V
Rated Current
8 / 4
Initial Power Draw
115 – 145 watt
Refrigeration Agent
R134A
Blowing Agent
Cyclopentane
Product Dimensions (in)
Width 22″ / Depth 23″ / Height 72.8″
Weight
66kg / 145lbs
Warranty
1 yr

Energy Consumption Guide (24h)

Room / Op. Temp
Fridge 35°F (2°C)
Freezer -10°F (-23°C)
Total W/A Hours
70°F (21°C)
455Wh / 36.4Ah
234Wh / 18.72Ah
689Wh / 55.12Ah
90°F (32°C)
469Wh / 45.52Ah
292Wh / 23.5Ah
861Wh / 68.9Ah


Model: C4P7.4SRVR



Total Volume
210 Liters / 7.4 cu.ft
Freezer Volume
48 Liters / 1.7 cu.ft
Refrigerator Volume
162 Liters / 5.7 cu.ft
Rated Operation Voltage
12V 9.6-17V / 24V 21 – 31.5 V
Rated Current
5 / 2.5
Initial Power Draw
73 – 105 watt
Refrigeration Agent
R134A
Blowing Agent
Cyclopentane
Product Dimensions (in)
Width 23.6″ / Depth 21.7″ / Height 56″
Weight
43kg / 94.6 lbs
Warranty
1 yr

Energy Consumption Guide (24h)

Room / Op. Temp
Fridge 35°F (2°C)
Freezer -10°F (-23°C)
Total W/A Hours
70°F (21°C)
361Wh / 28.8Ah
209Wh / 16.7Ah
570Wh / 45.5Ah
90°F (32°C)
450Wh / 36.07Ah
261Wh / 20.8Ah
712Wh / 57Ah


Model: C4P6.1SRVR



Total Volume
170 Liters / 6.1 cu.ft
Freezer Volume
45 Liters / 1.6 cu.ft
Refrigerator Volume
127 Liters / 4.5 cu.ft
Rated Operation Voltage
12V 9.6-17V / 24V 21-31.5V
Rated Current
5 / 2.5
Initial Power Draw
70 – 100 watt
Refrigeration Agent
R134A
Blowing Agent
Cyclopentane
Product Dimensions (in)
Width 20.5″ / Depth 19″ / Height 61″
Weight
39kg / 86lbs
Warranty
1 yr

Energy Consumption Guide (24h)

Room / Op. Temp
Fridge 35°F (2°C)
Freezer -10°F (-23°C)
Total W/A Hours
70°F (21°C)
361Wh / 28.8Ah
209Wh / 16.7Ah
570Wh / 45.5Ah
90°F (32°C)
450Wh / 36.07Ah
261Wh / 20.8Ah
712Wh / 57Ah
